E Glass 7628 Plain Woven Fiberglass Cloth Fiber

Short Description:

Weight:200 ± 10gsm
Surface Treatment:Silicon Coated
Weave Type:Plain Woven
Yarn Type:E-glass
Standing Temperature:550 degree, 550 Degree

Acceptance: OEM/ODM, Wholesale, Trade,

Payment: T/T, L/C, PayPal

Our factory has been producing Fiberglass since 1999.We want to be your best choice and your absolutely reliable business partner.

Any inquiries we are happy to reply, please feel free to send your questions and orders.

Product Detail

Product Tags

Product Display

Plain Woven Fiberglass Cloth
Fiberglass Cloth

Product Application

The raw material for fiberglass cloth is old glass or glass balls, which are made in four steps: melting, drawing, winding and weaving. Each bundle of raw fibre is made up of many monofilaments, each just a few microns in diameter, the larger ones more than twenty microns. Fibreglass fabric is the base material of hand-laid FRP, it is a plain fabric, the main strength is dependent on the warp and weft direction of the fabric. If you need high strength in the warp or weft direction, you can weave fiberglass cloth into a unidirectional fabric.

Applications of Fibreglass Cloth
Many of them are used in the process of hand gluing, and in the industrial application, it is mainly used for fireproofing and heat insulation. Fiberglass cloth is mainly used in the following ways

1.In the transport industry, fiberglass cloth is used in buses, yachts, tankers, cars and so on.

2.In the construction industry, fiberglass cloth is used in kitchens, columns and beams, decorative panels, fences and so on.

3.In the petrochemical industry, the applications include pipelines, anti-corrosion materials, storage tanks, acid, alkali, organic solvents and so on. the machinery industry, the application of artificial teeth and artificial bones, aircraft structure, machine parts, etc..

5.daily life in the tennis racket, fishing rod, bow and arrow, swimming pools, bowling venues and so on.

Specification and Physical Properties

Code  7628
Weight 200 ± 10gsm
Density Warp - 17±1/cm; Weft - 13±1/cm
High Temperature 550°C
Weave Type Plain Weave
Yarn Type E-glass
Width 1050mm ~ 1270mm
Length 50m/100m/150m/200m, or according to customer's requirements
Color White

1. Well-distributed, high strength, good vertical performance.
2. Fast impregnation, good molding property, easily removing air bubbles.

3. High mechanical strength, less strength loss in wet conditions.

Fiberglass Cloth 7628 is made of superfine glass wool. Fiberglass cloth is an engineering material, which has many excellent characteristics, such as anti-burning, corrosion resistance, stable structure, heat-isolating, minimum elongated shrinkage, high intensity, etc.


Fiberglass cloth could be produced into different widths, each roll is wound on suitable cardboard tubes with an inside diameter of 100mm,then put into a polyethylene bag, fastened to the bag entrance, and packed into a suitable cardboard box.

Product Storage and Transportation

Unless otherwise specified, the fiberglass products should be stored in a dry, cool and moisture proof area. Best used within 12 months after production date. They should remain in their original packaging until just prior to use. The products are suitable for delivery by the way of ship, train, or truck.
