High Temperature Resistant Fiberglass Texturized Yarn Insulation Material Yarn Glass Fiber

Short Description:

Product name：Fiberglass Texturized Yarn

Density：0.65-1.8

Application：Architecture/Petrochemical

Package：Woven Bag/Carton Box

Color：White

Tex Count ：1200-4800tex

Our factory has been producing fiberglass since 1999.
Acceptance: OEM/ODM, Wholesale, Trade,
Payment: T/T, L/C, PayPal
Our factory has been producing Fiberglass since 1999.We want to be your best choice and your absolutely reliable business partner.
Please feel free to send your questions and orders.

Send email to us Phone Whatsapp

Product Detail

Product Tags

Product Display

Product Application

Fiberglass Texturized Yarn for weaving is compatible with unsaturated polyester, vinyl ester and epoxy resins.Its excellent weaving property makes it suited for fiberglass product, such as roving cloth, combination mats, stitched mat,multi-axial fabric,geotextiles,molded grating.The end-use products are widely used in building & construction, wind power and yacht applications.

In everyday life, we see chevron fabrics of different thicknesses or twisted roving fabrics in the same direction, which is a reflection of another important use of twisted roving, which is for weaving. The twist-free fiberglass texturized yarn used is also called twist-free roving for weaving. Most of these fabrics are highlighted in the hand-fabricated FRP molding. The following requirements must be fulfilled for twisted roving for weaving: High abrasion resistance. Ease of tape formation. Since fiberglass texturized yarn is mainly used for weaving, fiberglass texturized yarn must be dried before weaving. In terms of tension, the main guarantee is that fiberglass texturized yarn should not be too high or too low, but fiberglass texturized yarn should be kept uniform. And in terms of drape to meet certain conditions. The annealing property should be good. When passing through the resin tank, it is guaranteed that it is easily moisturized by the resin, so the permeability must be good.

Specification and Physical Properties

Item	Linear Density	Resin Compatibility	Features	End Use
KGD-01D	800-4800	Asphalt	High strand strength, Low fuzz	Suitable in manufacture of geotextiles, used to reinforce high-speed road
KGD-02D	2000	EP	Fast wet out, Excellent mechanical property of the composite product, High modulus	Suitable in manufacture of UD or multiaxial fabric, used as reinforcement of large wind energy blade by vacuum infusion process
KGD-03D	300-2400	EP,Polyester	Excellent mechanical properties of the composite product	Suitable in manufacture of UD or multiaxial fabric, used as reinforcement of large wind energy blade by prepreg process
KGD-04D	1200,2400	EP	Excellent weaving property, Excellent mechanical properties of the composite product, High modulus	Suitable in manufacture of UD or multiaxial fabric used as reinforcement of large wind energy blade by vacuum infusion process
KGD-05D	200-9600	UP	Low fuzz,Excellent weaving property;Excellent mechanical property of the composite products	Suitable for manufacture of UD or multiaxial fabric used as reinforcement of large polyester wind energy blade
KGD-06D	100-300	UP,VE,UP	Excellent weaving property, Excellent mechanical properties of the composite product	Suitable in manufacture of light weight roving cloth and multiaxial fabric
KGD-07D	1200,2000,2400	EP,Polyester	Excellent weaving property; Excellent mechanical properties of the composite product	Suitable in manufacture of UD or multiaxial fabric, used as reinforcement of large wind energy blade by vacuum infusion processand prepreg process
KGD-08D	200-9600	UP,VE,UP	Excellent mechanical properties of the composite product	Suitable in manufacture of roving cloth used as reinforcement for pipes, yachts

1. Less hairiness, strong insulation, alkali resistance.

2.Elongation within the limits of elasticity and high tensile strength, so fiberglass texturized yarn absorbs a lot of impact energy.

3.Inorganic fiber, non-combustible, good chemical resistance.

4.good permeability, no white silk.

5.Not easy to burn,fiberglass texturized yarn can be fused into glassy beads at high temperature.

6.Good processability,fiberglass texturized yarn can be made into strands, bundles, felts, fabrics and other different forms of products.

7.Transparent and can transmit light.

8.Fusion with many kinds of resin surface treatment agent.

Packing

Fiberglass texturized yarn for spray up are available in small,single doff carton boxes but are generally palletized.

Product Storage and Transportation

Unless otherwise specified, the fiberglass texturized yarn products should be stored in a dry, cool and moisture proof area. Best used within 12 months after production date. They should remain in their original packaging until just prior to use. The products are suitable for delivery by the way of ship, train, or truck.
